The Hengyan PA-series mini electric wire-rope hoist is available from PA200 to PA1200, covering light home decoration work, medium-duty goods handling and construction-site lifting. According to the supplied product parameters, the series supports single-line and double-line lifting, with capacities from 100/200 kg up to 600/1200 kg.
| Model | Power | Lifting Height | Lifting Speed | Rated Load | Wire Rope | Product Size | Recommended Use |
|---|---|---|---|---|---|---|---|
| PA200 | 480 W | 12 / 6 m | 10 / 5 m/min | 100 / 200 kg | Ø 3 mm | Compact body | Home decoration, light goods |
| PA300 | 600 W | 12 / 6 m | 10 / 5 m/min | 150 / 300 kg | Ø 3 mm | Medium body | Home decoration, small cargo |
| PA400 | 950 W | 12 / 6 m | 10 / 5 m/min | 200 / 400 kg | Ø 4 mm | Medium body | Home decoration, furniture lifting |
| PA500 | 1020 W | 12 / 6 m | 10 / 5 m/min | 250 / 500 kg | Ø 4 mm | Length 38.5 cm; hook height 43 / 44 cm | Home decoration, grain lifting |
| PA600 | 1200 W | 12 / 6 m | 10 / 5 m/min | 300 / 600 kg | Ø 4 mm | Length 38.5 cm; hook height 43 / 44 cm | Home decoration, small & medium cargo |
| PA800 | 1300 W | 12 / 6 m | 10 / 5 m/min | 400 / 800 kg | Ø 5 mm | Length 40.5 cm; hook height 43 / 44 cm | Home decoration, medium cargo |
| PA1000 | 1600 W | 12 / 6 m | 10 / 5 m/min | 500 / 1000 kg | Ø 6 mm | Length 50 cm; hook height 47.5 / 55 cm | Construction, factory workshop |
| PA1200 | 2100 W | 12 / 6 m | 10 / 5 m/min | 600 / 1200 kg | Ø 6 mm | Length 50 cm; hook height 47.5 / 55 cm | Construction, warehouse logistics |
Parameters translated from the supplied product charts. PA500 / PA600 / PA800 are recommended for home decoration, grain lifting, furniture moving and small-to-medium goods handling. PA1000 / PA1200 are recommended for construction sites, factory workshops and warehouse logistics. Custom specifications available on request.
Mini Electric Hoist 220V PA200-PA1200 is part of HENGYAN's lifting equipment range for global distributors, importers and industrial buyers. The model should be selected according to rated load, working environment, lifting or pulling distance, voltage, duty cycle and target market requirements.
Designed for workshops, small warehouses, home improvement projects and light industrial lifting where compact size and quick installation matter.
Best for distributors and project buyers looking for 220V mini hoists with stable demand, simple packaging customization and repeatable spare parts.
The PA series covers 100 kg to 1200 kg models depending on single-line or double-line lifting configuration.
Yes. HENGYAN can support private labels, carton artwork, manual customization and model-name adjustments for distributors.
